手持示波表 Fluke PM97 9.5成新

厂家: 美国福禄克

Dual trace, hand held, oscilloscope/meter employing a 4.7 display - 3 2/3 digits.

Dual Trace 50 MHz Bandwidth
10 nanoseconds to 60 seconds per division
1 millivolt to 100 volts per division
40 nanosecond Glitch Capture
Stores 10 Front Panel Set-Ups
25 Mega samples per second
14 Cursor Measurements
Large Backlight LCD Display
Counts frequency from 1Hz to 5MHz to 50MHz with scope cursors
Min, Max, Avg, Record, Relative (zero), dBm, dBV, dBW, Audio Watts, % scale, frequency, smoothing, change alert.
Also has function generator with square wave, sine wave, voltage ramp or current ramp output waveforms.
Hard copy output available through Optical RS232C port.
Time/Division - 10ms to 60sec/div. Volts/Division - 1mV to 100V/div.
Maximum input volts - TrueRMS AC or AC+DC to 600V (1700V pk-pk).
Counts frequncy from 1 Hz to 5 MHz to 50 MHz with scope cursors.
